AC 220V Oven Temperature Controller RKC REX-C700 Thermocouple PT100,K Universal Input Relay Output 72*72mm Thermostat



Input: Thermocouple/RTD

Output: Relay/SSR

Power: 100-240VAC

Product Features:

  • Dual display for both set temperature and process temperature
  • Size, 96*96mm
  • Universal input, support 10 different types of  thermocouples and RTD inputs by customers selected at panels.
  • Auto-tune function can find the best PID parameter automatically
  • Displays temperature in Celsius
  • Four digits LED display can go up to "9999"
  • Can be powered by either DC or AC power source
  • Uses it for Kiln,Furnace,Oven,Incubator temperature control
  • Uses it in heating control as well as for cooling control
  • It is used in various industries to control and monitor process temperatures



Product Main Specifications:



Input type

TC: K, E, S, R, J, T, B, WRe3-WRe25.

RTD: Pt100, Cu50

DC voltage: 0~5V, 1~5V,0~10V.

DC current:  4~20mA

Input range

K (-200~+1300ºC), S (-50~+1600ºC), WRe3-WRe25 (0~2300ºC ), R (-50~+1600ºC), T (-200~400ºC), E (-200~900ºC), J (-200~1200ºC), B (350~1800ºC), Pt100 (-99.9~600.0ºC) or (-200~+600ºC), Cu50 (-50~150ºC)

Display

Two lines, Four digits. °C.

Display Resolution

1°C, 1°F, or 0.1°C, 0. 1°F, with Pt100

Accuracy

±0.5% or ±1 unit of full input range

Control mode

PID, On-Off

Output mode

Relay contact: 3A at 240 VAC.

SSR: 12VDC,

Current: 4~20 mA

Voltage: 0~10V

Alarm

Upper-limit bias alarm

Power consumption

<2 Watt

Power supply voltage rating

85~265VAC/50~60Hz

Dimensions

Rex-C700  72*72*110mm

Cautions:

  • Only clean the instrument when power off.
  • Please use a soft cloth or cotton paper to clean up the stain on the display.
  • Do not clean up or touch the display by hard matters in case of  any scrath.
  • Never use sharp & hard matters such ass screwdrivers or ball pan to touch the buttons on the panel,in case of any scrath or damage.

Packages:

  • 1×PID Digital Temperature Controller (NOT include thermocouple)

  • 1 x English User Manual

Write a review

Note: HTML is not translated!
Bad Good
Oven Temperature Controller RKC REX-C700 Thermocouple PT100 , K Universal Input Relay Output Thermostat
  • Stock: In Stock
  • Model: REX-C700
  • Weight: 40.00g
  • Dimensions: 72.00mm x 72.00mm x 110.00mm
190 samples sold
6,900.00DA
