Introduction
ZL-6290A (ZL-1000) is similar to STC-1000 and ITC-1000, with enhanced specification.
It has two outputs, one for cooling, and one for heating, to regulate temperature to a set-point.
It will judge heating or cooling mode automatically: if the room temperature is higher than set point, cooling mode; else heating mode.
More settings make application, such as incubator control, much better.
Note:
When 2 set-points are set to same value, and 2 hysteresis are set to same value, it will be same as stc1000/itc1000.
When 2 set-points are not same value, it could be a system like wine cabinet, or energy saving control for fish pool or incubator (not cooling immediately after heating stops).
The added NC (Normal Close) output can indicate: the heater stops.
Specification
Sensor: NTC
R25℃ = 10K, B25/85℃ = 3435K; R25℃ = 5K, B25/50℃ = 3470K
Setting range: -50.0 ~ 99.0℃, or -58.0 ~ 210.2℉
Display range: -50.0 ~ 99.9℃, or -58.0 ~ 211.8℉
Terminal: 2 * 1.5mm2 or 1 * 2.5mm2
Outputs: 10A * 2, 250Vac (under pure resistance load)
Working: -10~45℃, 5~85%RH without dew
Protection level: IP65 (Front side only)
Dimension: W78 x H34.5 x D71 (mm)
Installation drilling: W71 x H29 (mm)
Usage: Industrial
Cable Length: 2M
Model Number: ZL-6290A
Style: Wall Hanging
Max Measuring Temperature: 70°C- 99°C
Display Size: 1.9 Inches & Under
Theory: Temperature Controller
Display Type: Digital
Power Type: Charger
color:white + black
material: plastic
Package Contents:
1 * Thermostat controller
1 * Sensor
1 * English Manual
Only the above package content, other products are not included.
Note: Light shooting and different displays may cause the color of the item in the picture a little different from the real thing. The measurement allowed error is +/- 1-3cm.
